Magnetic Stripe Reader MR-300

MR300 Magnetic Stripe Reader provides you with a cost-effective magnetic stripe reader to satisfy the POS industries needs. MR300 is a well designed magnetic stripe reader with badge length 90mm and the data format complies with ISO 7810-7813, JISII standards. It reads magstripe cards with range from 300 to 4000 Oersted. MR300 is available for USB (HID), KB Wedge and RS232. Reading magnetic stripe card complied with ISO 7810~3 formats. Reading magnetic stripe card complied with JISII (Option). Magnetic stripe reader with badge length 9cm. Card Reading Speed: 10 to 100 cm per second. Reading 300 to 4000 Oersted cards. Support beep and LED for each stripe status indicators. Parameter program software for Windows series version. reading card data on single, dual, or triple track in one swipe. Magnetic Head Life 1,000,000 passes.


Specifications

Card Readers
Card Standard ISO 7810~7813 formats, JISII (Option).
Magnetic Head 1,000,000 passes.
Reader Interface TTL/KBW/RS232/USB
Reader Rate 10 to 100 cm per second -Bi-direction
Magnetic Track T1/T2/T3: 210/75/210 BPI Capacity T1/T2/T3: 79/40/107 Characters
Reader Power supply Output Voltage (Typ.) ±9V +5V±5% +5V±5%
Reader Operation Operating Temperature: 0 oC to 50 oC (32 o F to 122 o F)/ Storage Temperature -20 oC to 70 oC (-4 o F to 158 o F)/ Relative Humidity 20% to 95% (Non-condensing)
Reader Dimensions 90.00 mm X29.00 mm X 38.00 mm
Reader Weight Body Weight: 52 g ( 1.82 oz )/ Cable Weight: KBW 67g (2.36 oz)/ USB: 50.6g (1.78 oz)/ RS232: 70.4g (2.48 oz)
Reader Additional features Magnetic stripe reader with badge length 9 cm/ Reading 300 to 4000 Oersted cards/ Support beep and LED for each stripe status indicators/ Parameter program software for Windows series version/ Reading card data on single, dual, or triple track in one swipe/ Material PC & ABS/ Cable Length 150 mm ( 5.91 inch )/ Life Time MTBF (Calculated) 24,000 hours
