MS352 2D Scanner

Name: MS352 2D Scanner
Brand: UNITECH
Price: 1.00 EUR
Availability: InStock

MS352 2D Scanner

Downloads

File	Size	Download
MS352_Brochure.pdf	1.7MB	Download

Description

Scanner Unitech MS352 2D

MS352 fits into any environment, whether it is retail, warehouse or even a hospital. No need to worry about missing a beat in a noisy environment thanks to the vibration feedback the scanner gives. Next to this, the high transmission speed thanks to Bluetooth 4.2 connectivity; makes for quicker scanning.The sturdy materials and wide range scanning resolution, combined with a 2600 mAh LI-ION battery and a durable trigger make the MS352 an incredible value-for-money option for any environment. The Bluetooth 4.2 Dual Mode, Class 2 Range connectivity and a range of 30 meters in open air also make it incredibly connected for even faster and more repetitive scanning. The MS352 is both suited for RS232 interface project requirements as well as high density barcode application projects.

UNITECH

Specifications

Scanners
Reading mode	2D Imager
Scanning range/ Βάθος πεδίου	Decode Range: 3 mil Code39 (3 chars), 4 mil Code,5 mil Code39 (3 chars), 10 mil Code39 (3 chars), 13 mil UPC (6 chars), 20 mil Code39 (1 char), 5 mil QR (40 chars), 6.7 mil PDF417 (20 chars), 10 mil QR (20 chars), 20 mil QR (20 chars)./ HD series: 10 mm – 61 mm, 5 mm – 88 mm, 0 mm – 108 mm, 0 mm – 167 mm, 0 mm – 179 mm, 10 mm – 253 mm, 7 mm – 65 mm, 0 mm – 105 mm, 0 mm – 215 mm./ SR series:55 mm – 106 mm, 43 mm – 141 mm, 0 mm – 310 mm, 0 mm – 335 mm, 8 mm – 480 mm, 37 mm – 145 mm, 0 mm – 168 mm, 0 mm – 345 mm.
Scanning range/ Width of Field	Horizontal ± 42° / Vertical ± 26.5°
Scan Rate Ρυθμός σάρωσης	600 times per second Decoding Rate
Resolution	1280 x 800 pixels
Interfaces	Bluetooth 4.2 Dual Mode, Class 2 Range, RS232
Dimensions	Scanner dimension: 90.2mm x 70mm x 180mm/ Cradle dimension: 118mm x 89.5mm x 74mm
Weight	210g (Scanner only)/ 140g (Cradle only without cable)
Ambient light	0~100,000 LUX
Symbologies	1D: UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128, ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey, UK/ Plessey, China Post, China Finance, GS1 DataBar (formerly RSS) variants/ 2D: PDF417, MicroPDF417, QR code, DataMatrix, Aztec Code
Additional features	Communication: Radio Frequency MS352: 2.4-2.5GHz, Range MS352: 30 meters (open air)/ Operating temperature 0°C to 50°C, Storage temperature -40°C to 60°C, Humidity 5%-95% non-condensing, Drop resistance 1.5 m, IP rate IP51/ Operating voltage 5 ± 0.25 VDC, Scanner/ Cradle), Battery 1400 mAh Lithium-ion battery, Current scanner Working: 350mA / Standby: 20mA Current cradle Working: 60mA, Charging: max. 500mA, Charge Time 4 hours, Standby Time 4.5 days, Operating Time 46 hours (1 scan per 5 seconds)
