DS6878 Scanner 2D

Name: DS6878 Scanner 2D
Brand: ZEBRA
Price: 1.00 EUR
Availability: InStock

DS6878 Scanner 2D

Downloads

File	Size	Download
Zebra-DS6878-SR-Datasheet.pdf	251.8KB	Download

Description

Scanner Zebra DS6878 2D

Αdvanced imager reads 1D, 2D, PDF417 barcodes on both labels and mobile phone displays. Optional presentation cradle enables image capture, OCR and MICR. The DS6878-SR cordless 2D imager offers the complete data capture functionality required to streamline and error-proof everyday processes. Comfortable and easy-to-use, this single device can capture all common barcodes (1D, 2D and PDF417) on labels as well as on mobile phone displays. The optional hands-free presentation cradle enables additional advanced capabilities, signature, document and photo capture; optical character recognition (OCR) to capture text in documents; and MICR to capture numeric information on the bottom of checks. Delivers laser-like performance on both 1D and 2D codes. Αbility to survive 1.5m drops to concrete. IP43 sealing. USB charging. Bluetooth v2.1 with EDR.

ZEBRA

Specifications

Scanners
Reading mode	1D and 2D
Scanning range/ Βάθος πεδίου	32.8° H x 24.8° V Nominal
Scanning range/ Width of Field	+/- 65°; +/- 65°; 0-360
Scan Rate Ρυθμός σάρωσης	Motion Tolerance (Handheld): Up to 5 in./13 cm. per second for 13 mil UPC
Resolution	Minimum Element Resolution: Code 39 - 4.0 mil, Code 128 - 4.0 mil, Data Matrix - 6.0 mil, QR Code - 6.7 mil.
Interfaces	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485.
Dimensions	6.5 in. H x 2.6 in. W x 3.9 in. D/ 16.5 cm H x 6.6 cm W x 9.9 cm D
Weight	5.7 oz. / 161.6 g
Ambient light	Ambient Light Immunity: 107,600 Lux. Light Source Aiming Pattern: Linear 624nm Amber LED. Illumination (2) 645nm Super-Red LEDs
Sealing	IP52
Symbologies	1D: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma). 2D: PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes.
Additional features	Operating Temp. 32° F to 122° F / 0° to 50° C. / Drop Specs Withstands multiple 5 ft./1.5 m drops to concrete. /Humidity 5% to 95% RH (non-condensing) /Image Sensor: 640 x 480 pixels. Battery Capacity/ Battery Type: 2,400 mAh Li-Ion Battery. Scans Per Battery Charge2: 110,000 scans at 60 scans per minute or 50,000 scans at 10 scans per minute. Operating Time Per Full Charge2: 84.0 Hours
