LS2208 Scanner 1D

LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D
LS2208 Scanner 1D

Downloads

File Size Download
ls2208-spec-sheet-new-en-us.pdf 260.2KB Download

Scanner Zebra LS2208 1D

The affordable Symbol LS2208 handheld barcode scanner provides fast, reliable scanning in an ergonomic, lightweight form. The wide working range from near contact to 17 inches makes this device ideal for retail, hospital, education or government settings. Multiple on-board interfaces ensure integration with a variety of host systems. The LS2208 is designed for continuous usage all day, which significantly reduces downtime and repair costs. It provides accurate, first-time scanning. And since it is always ready for the next scan, the LS2208 can shorten check-out lines, improve customer service and increase productivity.

Specifications

Scanners
Reading mode 1D
Scanning range/ Βάθος πεδίου Scan Angle:35°/Skew:±10°/ Pitch:± 65°/Roll: ± 60°
Scanning range/ Width of Field Code 39: 3 mil:1.6 - 4.8 in./4.1 - 12.2 cm/ 4 mil:1.3 - 8.7 in./3.3 - 22.1 cm/ 5 mil:0.9 - 11.7 in./2.3 - 29.7 cm/ 7.5 mil: 0.1 - 19.1 in./0.3 - 48.5 cm/ 20 mil: 0 - 33.8 in./0 - 85.9 cm/ 40 mil: 1 - 43.1 in./2.5 -109.5 cm/ UPC: 13 mil (100%): 0 - 25.1 in./0 - 63.8 cm.
Scan Rate Ρυθμός σάρωσης 100 scans per second
Resolution Code 39: 3.0 mil minimum
Interfaces USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Dimensions 6.0 in. H x 2.5 in. W x 3.3 in. D/ 15.2 cm. H x 6.4 cm. W x 8.5 cm. D
Weight 5.3 oz./150.0 g
Ambient light 0 to 8,000 Foot Candles / 0 to 86,080 Lux; tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions; Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED4: 450 Ft. Candles (4,844 Lux) Sunlight: 8000 Ft. Candles (86,111 Lux)
Sealing IP30
Symbologies Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma). Refer to Product Reference Guide for complete list of symbologies.
Additional features Keyboard Support: Supports over 90 international keyboards/ User Indicators: Direct decode indicator, good decode LEDs, beeper (adjustable tone/volume)/Operating Temperature:32° to 122° F/0° to 50° C/ Storage Temperature: -40° to 158° F/-40° to 70° C/ Humidity: 5% - 95% RH, non-condensing/ Drop Specification: Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete/ Input Voltage Range: 4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply
