EK1799 Scanner 1D/2D

EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D
EK1799 Scanner 1D/2D

Downloads

File Size Download
EK-1799-KSG.pdf 849.26KB Download

KSG FG8975 Barcode Scanner 1D/2D, Pistol with base, Wi-fi + ΒΤ, 100 meters, USB , cable charge,high density.

Designed to meet a wide range of scanning needs in harsh working and demanding environments. Adopts two-color mold ABS+TPU and form at one time. Rugged IP52, shock-proof and anti-drop. Advanced decoding algorithm allowa to read damaged and stained codes, wrinkled codes and color barcodes quickly and accurately. Supports various keyboard languages. Ealily set up, no driver needed, plug and play operation. Only one-key for pairing and one-key for search function.  Operating continously for 12 hours and charging time needed 4-5 hours.

Specifications

Scanners
Reading mode 1D/2D
Scanning range/ Βάθος πεδίου Precision Barcode Depth of Field 3.34mil CODE 128 10mm—60mm. 5mil CODE128 5mm—90mm. .34mil EAN-13 10mm—55mm. 5mil EAN-13 5mm—85mm. 13.34mil EAN-13 20mm—190mm. 5mil PDF417 5mm—75mm. 10mil PDF417 5mm—190mm. 15mil PDF417 10mm—200mm. 10mil DM 5mm—100mm. 20mil DM 5mm—210mm.
Scanning range/ Width of Field Reading Angle: Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°.
Resolution 0.102mm / 4mils
Interfaces USB, Bluetooth
Ambient light Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux
Sealing IP52
Symbologies 1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded.*2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code*Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.
Additional features Image sensor 838×640 pixels Global Shutter. Operating Temp.0° C to 40° C/ Storage Temp. -40°C to 70°C/ Drop Specification Withstands multiple 4 ft./1.2 m drops to concrete. Input Voltage 5 VDC (+/- 10%)/500mA. 2.4G Transmission distance 100 meters ( Bluetooth 50m). Communication mode wireless real-time transmission/wired transmission/ storage mode. Battery capacity 2000mAh. Warranty 2 years.
Reading Speed 120fps
